Category Name : Radius And Angle Dresser, V-TDB B型砂輪修整器

Prodouts

Convex dressing range:0.8R-40R Convex dressing range:0-40R Max. wheel dressing diameter:250mm Max. wheel extending diameter:375mm
●	Positive setting of the diamond to absolute center with the special gage included with the dresser.
●	Simple,fast,accurate radius setting; no height gage or other set-up aids required. Radius is set on the ginder by measuring over the two pins or by inserting a gage block,as shown, for direct reading. Inside or outside radius is determined simply by sliding the dowel pin to the right for concave and to the left for convex.
●	4×90° gaduation in full 360° circle. 6 Minute vernier reading. Chrome plated.
●	One push-pull type knob for radius and angle control and for safer and faster operations.
●	ACCURACY. Exteremely close tolerances are held in the manufacture of this tool, assured by hardening and precision grinding of all critical parts. Ways are chrome hardened.
●	ECONOMY. Set-up and dressing time reduced to a bare minimum due to simplicity.
●	N.W.:10.5kg
