FEATURES：
| DIAMETER |
EACH STEP SIZE |
LENGTH |
ACCURACY IN DIAMETER |
ROUNDNESS TOLERENCE |
HARDNESS |
| 0.05~0.09 |
0.01 |
5~10 |
±0.5um |
0.5um |
HV480 |
| 0.10~0.19 |
0.01 |
20 |
±0.5um |
0.5um |
HV480 |
| 0.20~0.99 |
0.01 |
40 |
±1um |
0.8um |
HV650 |
| 1.00~10.00 |
0.01 |
50 |
±1um |
0.8um |
HV650 |
| 10.01~20.00 |
0.01 |
50 |
±1.5um |
1.6um |
HV650 |
| 20.00~30.00 |
0.01 |
50 |
±1.5um |
1.6um |
HV650 | EACH 0.01mm FOR ONE STEP SIZE
| ORDER NO. |
NOMINAL DIMENSION EACH 0.01mm FOR 1 PCS |
PCS/SET |
| VPG-0B |
0.50,0.51,0.52~1.00 |
51 |
| VPG-1A |
1.00,1.01,1.02~1.50 |
51 |
| VPG-1B |
1.50,1.51,1.52~2.00 |
51 |
| VPG-2A |
2.00,2.01,2.02~2.50 |
51 |
| VPG-2B |
2.50,2.51,2.52~3.00 |
51 |
| VPG-3A |
3.00,3.01,3.02~3.50 |
51 |
| VPG-3B |
3.50,3.51,3.52~4.00 |
51 |
| VPG-4A |
4.00,4.01,4.02~4.50 |
51 |
| VPG-4B |
4.50,4.51,4.52~5.00 |
51 |
| VPG-5A |
5.00,5.01,5.02~5.50 |
51 |
| VPG-5B |
5.50,5.51,5.52~6.00 |
51 |
| VPG-6A |
6.00,6.01,6.02~6.50 |
51 |
| VPG-6B |
6.50,6.51,6.52~7.00 |
51 |
| VPG-7A |
7.00,7.01,7.02~7.50 |
51 |
| VPG-7B |
7.50,7.51,7.52~8.00 |
51 |
| VPG-8A |
8.00,8.01,8.02~8.50 |
51 |
| VPG-8B |
8.50,8.51,8.52~9.00 |
51 |
| VPG-9A |
9.00,9.01,9.02~9.50 |
51 |
| VPG-9B |
9.50,9.51,9.52~10.00 |
51 |
| VPG-10A |
10.00,10.01,10.02~10.50 |
51 |
| VPG-10B |
10.50,10.51,10.52~11.00 |
51 | |
|
